Spring Wound Countdown Timer, Decorator Style, 125-277 VAC, 50/60 Hz, DPST, 60 Minute Max, Without Hold, Ivory
Model#FD460M
- This product has been discontinued.Please visit our discontinued products page to view a comparable alternative productProduct is non purchasable
Proposition 65 Warning for California residents
Spring Wound Countdown Timer, Decorator Style, 125-277 VAC, 50/60 Hz, DPST, 60 Minute Max, Without Hold, Ivory
Model#FD460M
- This product has been discontinued.Please visit our discontinued products page to view a comparable alternative productProduct is non purchasable
- Proposition 65 Warning for California residents
- 60-Minute timer
- DPST (Double-Pole Single-Throw)
- No electricity required to operate
- Replaces any standard or decorator single- or multi-gang wall switch
- Automatically limits ON time for energy consuming loads
- Quick and easy installation
- Time-saving up front terminal connection with teeter-type terminals
- Breaks circuit at end of timing cycle
- Incandescent/fluorescent/CFL/LED compatible
- No neutral connection is required
- Air Movement & Ventilation
- Indoor Lighting Control
- Motor Control
- Outdoor Lighting Control
Application Compatibilities CFL, Fluorescent, Incandescent, LED Brand Intermatic California Proposition 65 DEHP Color Ivory Countdown Time 60 min Country of Origin (Intermatic) TUNISIA CSA Certification cCSAus Hold Mode Included No Input Voltage Range(s) 125-277 VAC, 50/60 Hz Mechanism Type Analog/Mechanical Motor Load Ratings Ranges 1 HP, 125 VAC; 2 HP, 250 VAC Neutral Connection Required No Operation Mode Countdown Other Certifications and Compatibilities RU Packaging Applications Bathroom Fans, Garage Lights, Lights, Storage Closets, Whirlpools, Whole House Fans Resistive Heater 20 A, 2500 W, 125 VAC; 10 A, 2500 W, 250 VAC; 10 A, 2770 W, 277 VAC Switch Type DPST Tungsten (Incandescent) Range(s) 7 A, 125 VAC, 50/60 Hz, 875 W Tungsten Incandescent 7 A, 125 VAC, 50 Hz, 7 A, 125 VAC, 60 Hz, 875 W Wall Plate Configurations Single-Gang, Multi-Gang Warranty Period 1-Year limited Wiring Configurations Single Auto Start/Stop False Check Valve False DOE Compliant False Freeze protection False Operating Temperature Max (°C) 49 Operating Temperature Max (°F) 120 Operating Temperature Min (°C) 4 Operating Temperature Min (°F) 40 Product Depth (in) 1.25 Product Depth (mm) 31.8 Product Height (in) 4.125 Product Height (mm) 104.8 Product Width (in) 1.75 Product Width (mm) 44.5 submersible False Unit Carton Height (in) 4.63 Unit Carton Length (in) 2.88 Unit Carton Weight (lb) 0.299 Unit Carton Width (in) 2.13 Units Per Pallet 1200 UV Resiliant Outdoor Enclosure False
