7-Day Heavy-Duty Programmable Timer, 120-277 VAC, 15A, White
Model#ST01
$
Proposition 65 Warning for California residents
7-Day Heavy-Duty Programmable Timer, 120-277 VAC, 15A, White
Model#ST01
$
- Proposition 65 Warning for California residents
- Versatile 7-day programmable schedules with up to 40 ON/OFF events
- Astronomic clock feature determines dawn and dusk times
- Automatic Daylight Saving Time (DST) adjustment
- Random mode varies ON/OFF schedule to provide a "lived-in" appearance
- Single or 3-way switch compatible installation
- Incandescent/fluorescent/CFL/LED compatible
- Isolated switch allows timer to be used with any load type, including AC and DC loads
- Replaceable CR2 lithium battery provides up to three years of operation
- No neutral wire connection enables easy retrofitting and quicker installation
- Decorator switch plate not included
- View FAQs
- Air Movement & Ventilation
- Indoor Lighting Control
- Outdoor Lighting Control
Application Compatibilities CFL, Fluorescent, Incandescent, LED Backup Protection Time 3 Years Backup Type Battery Battery Service Type Replaceable Battery Type CR2 Lithium Brand Intermatic California Proposition 65 DEHP Color White Country of Origin (Intermatic) CHINA CSA Certification cCSAus DC loads 4 A, 12 VDC; 2 A, 28 VDC Inductive 4 A, 208 VAC, 50 Hz, 4 A, 208 VAC, 60 Hz, 4 A, 240 VAC, 50 Hz, 4 A, 240 VAC, 60 Hz, 4 A, 277 VAC, 50 Hz, 4 A, 277 VAC, 60 Hz, 8 A, 120 VAC, 50 Hz, 8 A, 120 VAC, 60 Hz Inductive Load Ratings Ranges 8 A, 120 VAC, 50/60 Hz; 4 A, 208-277 VAC, 50/60 Hz Input Voltage Range(s) 120-277 VAC, 50/60 Hz Max Load Handling Capability 15 A Maximum On/Off Operations 40 Mechanism Type Digital/Electrical Minimum On/Off Times 1 min Motor Load Ratings Ranges 1 HP, 120 VAC; 2 HP, 240 VAC Neutral Connection Required No Operation Features Astronomic, Daylight Saving Time Operation Mode 24 hour Other Certifications and Compatibilities Title 20 Packaging Applications Fans, Lighting, Motors Tungsten (Incandescent) Range(s) 1800 W, 120 VAC; 1248-1662 W, 208-277 VAC Wall Plate Configurations Single-Gang Warranty Period 1-Year limited Wiring Configurations 3-Way, Single Auto Start/Stop false Check Valve false DOE Compliant false Freeze protection false Operating Temperature Max (°C) 40 Operating Temperature Max (°F) 104 Operating Temperature Min (°C) 0 Operating Temperature Min (°F) 32 Product Depth (in) 1.813 Product Depth (mm) 46 Product Height (in) 4.125 Product Height (mm) 104.8 Product Width (in) 1.75 Product Width (mm) 44.5 submersible false Unit Carton Height (in) 4.625 Unit Carton Length (in) 2.875 Unit Carton Weight (lb) 0.4 Unit Carton Width (in) 2.125 Units Per Pallet 2160 UV Resiliant Outdoor Enclosure false
