Locking Type Receptacle, 7-Pin, C136.41 Compliant, 12" lead
Model#K171H
$
Proposition 65 Warning for California residents
Locking Type Receptacle, 7-Pin, C136.41 Compliant, 12" lead
Model#K171H
$
- Proposition 65 Warning for California residents
- NEMA receptacle with 3-prong power sockets
- Two gold plated contact pads for dimming control signals
- Two gold plated contact pads for extra control or sensor input signals
- Integrated sealing gasket
- Compliant to ANSI C136.41 specifications
Base Material UV Stabilized Polycarbonate (UL94-5 VA) Brand Intermatic California Proposition 65 DEHP Color Black Country of Origin (Intermatic) CHINA CSA Certification CSA C22 No. M1986 Gasket (Integrated) Thermal Elastomer Other Certifications and Compatibilities Ansi C136.41, cRUus Packaging Applications Exterior Lighting, Landscape Lighting, Parking Lots, Pedestrian Pathway Lighting, Street Lighting Power Contacts Material Brass/Phosphor Bronze Power Contacts Rating 480 V max, 15 A max Signal Contacts Material Nickel/Gold Plated Bronze Signal Contacts Rating 30 VDC, 0.25 A max UL Standard UL773 Warranty Period 1-Year limited Wire Leads #14 AWG, 105°C, AWM1015, Power, #18 AWG, 105°C, AWM1015, Signal Auto Start/Stop false Check Valve false DOE Compliant false Freeze protection false Operating Temperature Max (°C) 70 Operating Temperature Max (°F) 158 Operating Temperature Min (°C) -40 Operating Temperature Min (°F) -40 Product Height (in) 1.5 Product Height (mm) 38 submersible false Unit Carton Height (in) 2.63 Unit Carton Length (in) 3.22 Unit Carton Weight (lb) 0.33 Unit Carton Width (in) 3.22 Units Per Pallet 288 UV Resiliant Outdoor Enclosure false
